Digital product technology implementation elements
In order to solve the shortcomings of the above-mentioned prior art, the utility model aims to provide a solution that does not require screw locking, which can not only avoid the slipping problem caused by multiple screw locking, but also prevent the shell from being damaged due to impact and falling, while reducing the assembly process and improving the production efficiency of Plastic Parts Manufacturers.
To this end, the technical solution of the utility model includes:
1. Shell structure
The product of this plastic molding manufacturing inc consists of a shell and a bracket arranged inside the shell. One end of the shell is open, and the other end is provided with a plurality of bayonet holes. The side wall of the shell is provided with a support plate, one end of the bracket is provided with a two-way clamp corresponding to the bayonet hole, and the other end is provided with a sealing plate matching the shell opening. The two-way clip is composed of two symmetrically arranged clips.
2. Panel design
Furthermore, the shell also includes a panel for covering the clip.
3. Limiting support mechanism
Preferably, a limiting support mechanism is provided on the bottom wall of the shell, and a slide corresponding to the limiting support mechanism is provided on the bracket. The limiting support mechanism includes two parallel baffles, which are perpendicular to the bottom wall of the shell and have a trapezoidal structure, with a thinner end close to the opening and a thicker end away from the opening.
4. Enhanced stability
A limiting support mechanism is also provided on the bottom wall of the shell, and a corresponding slide is provided on the bracket. The limiting support mechanism also includes two parallel baffles, and is provided with a first locking tooth, and a corresponding second locking tooth is provided on the baffle, which enhances the overall stability.
Beneficial effect
By adopting the above technical solution, the utility model effectively combines the upper shell and the lower shell together, reduces the need for mold opening, and avoids the problem of slipping caused by multiple screw locking. At the same time, this design can effectively prevent the shell from breaking due to impact and falling, significantly reduce the assembly process, reduce production costs, increase the reuse rate of the shell, and greatly improve production efficiency.
As a professional plastic molding manufacturing inc, we are committed to providing customers with high-quality and efficient digital product shell solutions.
